Low Purge Pressure (LPP) Flare Tip Integration for IOCL Paradip Refinery
CRA executed the engineering, supply, and system-level integration of a Low Purge Pressure (LPP) flare tip for the flare system at IOCL’s Paradip Refinery, engineered to deliver safe, stable, and efficient flaring under low-flow, intermittent, and purge-only operating conditions. The solution minimizes continuous purge gas consumption while effectively preventing air ingress into the flare stack, ensuring combustion stability and operational safety. The system demonstrates CRA’s advanced flare combustion engineering capability for large-scale refinery environments, where consistent performance, safety, and operability must be maintained across wide turndown ratios.
The engineering challenges associated with low-flow refinery off-gas flaring
Refinery flare systems operate under highly dynamic conditions — ranging from near-zero purge flow during normal operation to sudden relief events during process upsets. The Paradip Refinery required a solution capable of addressing the following challenges:
- Prevention of air ingress during low or no-flow conditions
- Reduction of continuous purge gas losses without compromising safety
- Stable flame behavior during intermittent and fluctuating gas release
- Compatibility with low-pressure flare operation
- Smokeless combustion with controlled thermal radiation
- High ignition reliability suitable for refinery-grade duty
Failure to manage these conditions could lead to flame instability, unsafe stack conditions, or excessive operational losses.
The engineered LPP flare tip solution delivered by CRA
CRA supplied and integrated a Low Purge Pressure (LPP) flare tip for refinery off-gas service, engineered to reduce purge gas consumption while maintaining flame stability and operational safety, and fully compatible with IOCL’s existing flare infrastructure for reliable operation under low and intermittent flow conditions. The design incorporates an optimized molecular velocity seal that effectively prevents air ingress at substantially reduced purge gas flow rates.
Flare Tip Design & Engineering Features
- LPP Seal Design
Molecular velocity sealing prevents air ingress during low-flow and idle operation. - Low-Pressure Combustion Geometry
Geometry optimized for stable flame retention under fluctuating flow. - Pilot Ignition System
Reliable ignition using low-pressure fuel gas. - Smokeless Combustion
Controlled radiation with minimal smoke formation. - Mechanical Integrity
Refinery-grade design for continuous, high-temperature operation.
The design philosophy adopted for purge reduction and air ingress prevention
The design philosophy focused on ensuring flare stack safety and combustion stability during extended low-flow and purge-only operating conditions while minimizing continuous purge gas consumption. A low purge pressure approach was adopted to prevent air ingress through aerodynamic sealing rather than excess purge flow, enabling stable operation across wide turndown ratios. The flare tip geometry and ignition philosophy were engineered to support reliable flame retention, smooth transition during sudden flow variations, and controlled radiation, ensuring compatibility with refinery operating practices and long-term reliability.
The key engineering features of the LPP flare tip system
The design philosophy focused on maintaining flare stack safety and combustion stability during extended low-flow and purge-only operating conditions while minimizing continuous purge gas consumption. A low purge pressure approach was adopted to prevent air ingress through aerodynamic sealing rather than excess purge flow, enabling reliable operation across wide turndown ratios and compatibility with refinery operating practices.
- Low Purge Pressure Concept
Prevents air ingress using aerodynamic sealing instead of high purge rates. - Wide Turndown Stability
Ensures stable flame behavior during low, intermittent, and sudden flow conditions. - Combustion Reliability
Supports smooth flame transition and retention under fluctuating operating regimes. - Radiation Control
Maintains acceptable thermal radiation levels for refinery safety. - Refinery Compatibility
Aligns with existing flare infrastructure and long-term operational requirements.
The manufacturing and quality assurance approach followed during execution
Manufacturing was executed under controlled quality systems to ensure mechanical integrity, dimensional accuracy, and compliance with refinery and oil & gas industry standards. All activities were supported by defined inspection and testing protocols, documentation control, and traceability to ensure consistency, reliability, and readiness for integration within IOCL’s flare infrastructure.
- Controlled Fabrication
Manufacturing carried out under defined procedures and approved drawings. - Quality Assurance & Control
QA/QC processes implemented with inspection and test plans. - Material Traceability
Full traceability of critical materials and components maintained. - Dimensional & Visual Inspection
Verification of geometry, fit-up, and workmanship. - Documentation Package
Delivery of manufacturing records, QA/QC dossiers, and O&M manuals.
The operational outcomes and technical significance of the integrated LPP flare tip solution
The integrated Low Purge Pressure (LPP) flare tip solution delivered reliable refinery off-gas flaring under low and intermittent operating conditions while significantly reducing continuous purge gas consumption. Stable flame behavior was maintained across operating regimes, with effective air ingress prevention and controlled radiation, enhancing overall flare system safety and operational efficiency at IOCL’s Paradip Refinery.
- Stable Operation
Reliable performance during low-flow, intermittent, and purge-only conditions. - Purge Optimization
Reduced purge gas consumption without compromising stack safety. - Air Ingress Prevention
Effective aerodynamic sealing maintained during idle operation. - Combustion Performance
Smokeless flaring with controlled thermal radiation. - Engineering Validation
Demonstrated CRA’s capability in LPP flare design and refinery integration.
